Operation diagnosis
6
9.1
Sending traps
Basic - L3P
Release
4.0
11/07
The events which can be selected are:
Name Meaning
Authentication The switch has rejected an unauthorized access attempt (see the Access
for IP Addresses and Port Security dialog).
Cold Start The Switch has been switched on.
Link Down At one port of the switch, the link to the device connected there has been
interrupted.
Link Up At one port of the Switch, the link to a device connected there has been
established.
Spanning Tree The topology of the Rapid Spanning Tree has changed.
Chassis Encompasses the following events: .
Encompasses the following events: - The status of a supply voltage has
changed (see the System dialog). - Signaling relay: The status of the signal
contact has changed. To take this event into account, you activate "Trap
for status change" in the Diagnostics:Signal Contact 1/2 dialog.-
An error has occurred in connection with the SNTP. – A media module was
added or removed.– The ACA AutoConfiguration Adapter was added or re-
moved.– The temperature threshold was exceeded/not reached.
Redundancy The redundancy status of the Hiper-Ring or the redundant ring/network
coupling has changed.
Port Security At one port a data packet has been received from an unauthorized terminal
device (see the Port Security dialog).
Bridge Although the BPDU Guard function is active at a port, a BPDU was re-
ceived (see Redundancy user manual, "Rapid Spanning Tree").
Table 15: Trap categories
