Operation diagnosis
22
9.8
Topology discovery
Basic - L3P
Release
4.0
11/07
If several devices are connected to one port, for example via a hub, the
table will contain one line for each connected device.
If
X devices with active topology discovery function and
X devices without active topology discovery function
are connected to a port, the topology table hides the devices without
active topology discovery.
If
X only devices without active topology discovery are connected to a
port, the table will contain one line for this port to represent all devic-
es. This line contains the number of connected devices.
MAC addresses of devices that the topology table hides for the sake
of clarity, are located in the address table (FDB) . (see on page 124
"Entering static address entries").
