Operation diagnosis
Basic - L3P
Release
4.0
11/07
9.11
Monitoring port traffic (port mirroring)
29
Select the source port whose data traffic you want to observe.
Select the destination port to which you have connected your man-
agement tool.
Select "enabled" to switch on the function.
The "Delete" button in the dialog allows you to reset all the port mirroring
settings of the device to the state on delivery.
Note: In active port mirroring, the specified port is used solely for obser-
vation purposes.
Figure 60: Port Mirroring dialog
