Hirschmann MACH104-20TX-FR Series User Manual

Installation MACH104
Release 08 01/2019
37
6 Technical data
6.1 General technical data
Dimensions See “Dimension drawings” on page 38.
Weight MACH104-20TX-F... 9.26 lb (4.2 kg)
MACH104-20TX-FR... 9.7 lb (4.4 kg)
MACH104-20TX-F-4-PoE... 10.14 lb (4.6 kg)
Supply voltage Rated voltage range 100 V AC ... 240 V AC, 50 Hz ... 60 Hz
Voltage range including
maximum tolerances
90 V AC ... 265 V AC, 47 Hz ... 63 Hz
Current
consumption
Rated current for devices
without PoE
max. 0.3 A (240 V AC)
max. 0.5 A (100 V AC)
Rated current for devices with
PoE
max. 0.9 A (240 V AC)
max. 1.7 A (100 V AC)
Activation current typ. < 40 A at 265 V AC and cold start
PoE power Maximum number of Powered
Devices (PDs)
This applies to the following device
variants only:
MACH104-20TX-F-4-PoE...
4 × Powered Device (PD) Class 0 (15.4 W)
Power loss buffer > 12 ms (115 V AC)
Overload current
protection at input
Non-replaceable fuse
Climatic conditions
during operation
Ambient air temperature
a
a. Temperature of the ambient air at a distance of 2 in (5 cm) from the device
+32 °F ... +122 °F (0 °C ... +50 °C)
Humidity 20 % ... 90 %
(non-condensing)
Air pressure min. 795 hPa (+6562 ft; +2000 m)
max. 1060 hPa (−1312 ft; −400 m)
Climatic conditions
during storage
Ambient air temperature
b
b. Temperature of the ambient air at a distance of 2 in (5 cm) from the device
–4 °F ... +185 °F (−20 °C ... +85 °C)
Humidity 10 % ... 95 %
(non-condensing)
Air pressure min. 700 hPa (+9842 ft; +3000 m)
max. 1060 hPa (−1312 ft; −400 m)
Signal contact Switching current max. 1 A, SELV
Switching voltage max. 60 V DC or max. 30 V AC, SELV
Connection type 2-pin terminal block
max. conductor cross section AWG16
(1.3 mm²)
Tightening torque 2.2 lb-in (0.25 Nm)
Pollution degree 2
Protection classes Laser protection Class 1 in compliance with IEC 60825-1
Degree of protection IP30
