Hirschmann MACH104-20TX-FR Series User Manual

42
Installation MACH104
Release
08
01/2019
Product code
M-SFP-BIDI...
Mode
a
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/O
cable length
b
b. Including 3 dB system reserve when compliance with the fiber data is observed.
Fiber
attenuation
Dispersion
Type A LX/LC EEC SM 1310 nm 1550 nm 9/125 µm 0 dB ... 11 dB 0 km ... 12.43 mi
(0 km ... 20 km)
0.4 dB/km 3.5 ps/(nm×km)
Type B LX/LC EEC SM 1550 nm 1310 nm 9/125 µm 0 dB ... 11 dB 0 mi ... 12.43 mi
(0 km ... 20 km)
0.25 dB/km 19 ps/(nm×km)
Type A LH/LC EEC LH 1490 nm 1590 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Type B LH/LC EEC LH 1590 nm 1490 nm 9/125 µm 5 dB ... 24 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Table 7: F/O port (bidirectional Gigabit Ethernet SFP transceiver)
