MAINTENANCE
7-67
•
F
usible Link (Main F
use)
In case the star
ter won
’t rotate ev
en if the key switch is
turned to the ST
AR
T position, fusible link may the cause of
the trouble. Remov
e the cov
er next to the engine coolant
reservoir to check the fuse. Replace it if blown.
21-
+ Side (Red)

45A
22-
− Side (Black)

65A
M1U1-07-023
21
22
Battery
258
260
