Hitachi CU-HD1500 - Output, Return, and Assignment Settings

13
Function menu
OUTPUT SELECT menu
RETURN SELECT menu
ASSIGNMENT menu
Item Setting Factory setting Description
HIGH SPEED 1080i,720p 1080i Assigns output signal of HIGH SPEED OUTPUT
connector
.
HD1[1/2] 1080i,720p,
TRUNK VIDEO
1080i Assigns output signal of HD1[1/2] connector.
When TRUNK VIDEO is selected, an external
video source (1080i) is fed from CA-HF1500.
HD/SD1[1/2] 1080i,720p,SD 1080i Assigns output signal of HD/SD[1/2] connector.
HD/SD2[1/2] 1080i,720p, SD 1080i Assigns output signal of HD/SD[1/2] connector.
WFM/PIX 1080i,720p, SD 1080i Assigns output signal of WFM/PIX connectors.
ASPECT[SD] 16:9, 4:3 16:9 Sets aspect ratio of SD video.
■ＯＵＴＰＵＴ ＳＥＬＥＣＴ
ＨＩＧＨ ＳＰＥＥＤ ： １０８０ｉ
ＨＤ１［１／２］ ： １０８０ｉ
ＨＤ／ＳＤ１［１／２］ ： １０８０ｉ
ＨＤ／ＳＤ２［１／２］ ： １０８０ｉ
ＷＦＭ／ＰＩＸ ： １０８０ｉ
ＡＳＰＥＣＴ ［ＳＤ］ : １６：９
Item Setting Factory setting Description
CH1 RET.A1 Assigns the return video signal
to CH1 selected
when CA-HF1500 RET switch is set to 1.
CH2
RET.A1,RET.A2,
RET.A3,RET.A4
RET.A2
Assigns the return video signal
to CH2 selected
when CA-HF1500 RET switch is set to 2.
CH3 RET.A3 Assigns the return video signal
to CH3 selected
when CA-HF1500 RET switch is set to 3.
CH4 RET.A4 Assigns the return video signal
to CH4 selected
when CA-HF1500 RET switch is set to 4.
CA HD-SDI2 RET.B1,RET.B2 RET.B1 Assigns the return video signal to the HD-
SDI2
output on CA-HF1500.
ASSIGNMENT
- Moves to the ASSIGNMENT submenu.
■ＲＥＴＵＲＮ ＳＥＬＥＣＴ
ＲＥＴ．ＣＨ ＳＥＬＥＣＴ
ＣＨ１ ：ＲＥＴ．Ａ１
ＣＨ２ ：ＲＥＴ．Ａ２
ＣＨ３ ：ＲＥＴ．Ａ３
ＣＨ４ ：ＲＥＴ．Ａ４
ＣＡ ＨＤ－ＳＤＩ２ ：ＲＥＴ．Ｂ１
ＡＳＳＩＧＮＭＥＮＴ：
Item Setting Factory setting Description
RET.A1 1080i Assigns the TV format to RET.A1.
RET.A2 1080i
Assigns the TV format to RET.A2.
RET.A3 1080i
Assigns the TV format to RET.A3.
RET.A4 1080i
Assigns the TV format to RET.A4.
RET.B1 1080i
Assigns the TV format to RET.B1.
RET.B2
1080i,
720p,
SD SDI 16:9
SD SDI 4:3
1080i
Assigns the TV format to RET.B2.
■ＡＳＳＩＧＮＭＥＮＴ
ＳＥＬＥＣＴ ＴＹＰＥ
ＲＥＴ．Ａ１ ：１０８０ｉ
ＲＥＴ．Ａ２ ：１０８０ｉ
ＲＥＴ．Ａ３ ：１０８０ｉ
ＲＥＴ．Ａ４ ：１０８０ｉ
ＲＥＴ．Ｂ１ ：１０８０ｉ
ＲＥＴ．Ｂ１ ：１０８０ｉ
