Hitachi CU-HD1500 - Switch Setting for AC Power Supply; Front Panel

23
Service information
Switch setting for AC power supply
J (Japan) ：AC 100V 50/60Hz
U (U.S.A.) ：AC 117V 60Hz
E (Europe )：AC 230V 50Hz
Procedure
1. Loose two screws and lift the front panel slightly, and then pull it open.
2. Set two switches to supplied AC power voltage according to the diagram.
Inside of front panel
100V
117V
230V
Screw
Screw
Front panel
