Hitachi CU-HD1500 - Output Signals

32
Specifications
Output signals
Camera Control Unit CU-HD1500 (OUTPUT)
HIGH SPEED OUTPUT
LINK A, LINK B, LINK C (1/2)
HD-SDI
(Embedded 2-Chnl audio available)
・1080i : SMPTE292M
・720p ： SMPTE292M
BNC x6(x2+x2+x2)
DIGITAL OUT
HD1 (1/2)
HD-SDI
(Embedded 2-Chnl audio available)
・1080i : SMPTE292M
・720p ： SMPTE292M
BNC x2
DIGITAL OUT
HD/SD1～HD/SD2 (1/2)
HD-SDI or SD-SDI selectable
(Embedded 2-Chnl audio available)
・1080i : SMPTE292M
・720p ：SMPTE292M
・SD-SDI : SMPTE259M-C
BNC x4 (x2 + x2)
DIGITAL OUT
HD/SD3 (WFM)
HD-SDI or SD-SDI selectable WFM
(Embedded 2-Chnl audio available)
・1080i : SMPTE292M
・720p ：SMPTE292M
・SD-SDI : SMPTE259M-C
BNC x1
DIGITAL OUT
HD/SD3 (PIX)
HD-SDI or SD-SDI selectable PIX
(Embedded 2-Chnl audio available)
・1080i : SMPTE292M
・720p ：SMPTE292M
・SD-SDI : SMPTE259M-C
BNC x1
MIC OUT 1 0dBm/600Ω XLR-3pin
MIC OUT 2 0dBm/600Ω XLR-3pin
INTERCOM (HEAD SET) 0dBu MAX+15dB XLR-5pin(Female)
Remote 1 1.5Vp-p 4pin
Remote 2 1.5Vp-p 4pin
Remote 3 Remote RJ-45
COMMUNICATION D-sub 25pin
・INTERCOM
0dBm , 600Ω at 4Wire
0dBu or -15dBu ,200Ω at 2Wire
TALLY OUT(R/G) Contact D-sub 9pin
24Vdc, 10mA
WFM CONTROL WFM 0-7 0/5V D-sub 15pin
MIC REMOTE MIC1,2 Gain D-sub 15pin
TRUNK
RS-422 (150k baud)
(RS-232C : Option)
D-Sub 9 pin
