Hitachi CU-HD1500 - SD Video Processing Settings

15
Function menu
SD DTL menu
SD MASKING menu
■ＳＤ ＤＴＬ
ＳＤ ＤＴＬ ：ＯＮ
Ｈ ＧＡＩＮ ： ０
Ｖ ＧＡＩＮ ： ０
Ｈ ＣＲＩＳＰ ：－１２８
Ｖ ＣＲＩＳＰ ：－１２８
ＤＴＬ ＦＲＥＱ ：５ＭＨｚ
ＬＥＶＥＬ ＤＥＰ ：－１２８
ＬＥＬ ＤＥＰ ＳＬＰ：－１２８
Item Setting Factory setting Description
SD DTL OFF,ON ON Enable the detail effect specialized for
SDTV.
H GAIN -128 to +127 0 Adjusts the horizontal detail level.
V GAIN -128 to +127 0 Adjusts the vertical detail level.
H CRISP -128 to +127 -128 Adjusts the lower threshold level to enable
horizontal detail in order not to emphasize
noise.
V CRISP -128 to +127 -128 Adjusts the lower threshold level to enable
vertical detail in order not to emphasize
noise.
DTL FREQ 4MHz,5MHz,6MHz,
7MHz,8MHz
5MHz Set the detail frequency to emphasize.
LEVEL DEP -128 to +127 -128 Adjusts the detail level on dark area of
image.
LEV DEP SLP -128 to +127 -128 Adjusts the slope of detail effect on dark
area of image.
■ＳＤ ＭＡＳＫＩＮＧ
ＳＤ ＭＡＳＫＩＮＧ ：ＯＦＦ
Ｒ－Ｇ： ０ Ｒ－Ｂ： ０
Ｇ－Ｂ： ０ Ｇ－Ｒ： ０
Ｂ－Ｒ： ０ Ｂ－Ｇ： ０
ＳＤ ＭＡＴＲＩＸ ：ＯＮ
Item Setting Factory setting Description
SD MASKING OFF,ON OFF Enable the linear masking effect specialized
for SDTV.
R-G -128 to +127 0 Adjust liner matrix R-G parameter offset.
R-B -128 to +127 0 Adjust liner matrix R-B parameter offset.
G-B -128 to +127 0 Adjust liner matrix G-B parameter offset.
G-R -128 to +127 0 Adjust liner matrix G-R parameter offset.
B-R -128 to +127 0 Adjust liner matrix B-R parameter offset.
B-G -128 to +127 0 Adjust liner matrix B-G parameter offset.
SD MATRIX OFF,ON ON Enable the color matrix conversion from
HDTV to SDTV.
