Hitachi CU-HD1500 - Specifications; Input and Output Signals

31
Specifications
Camera Control Unit CU-HD1500
(J) AC100V 50Hz/60Hz (CU-HD1500J)
(U) AC117V 60Hz (CU-HD1500U)
Power supply voltage
(E) AC230V 50Hz (CU-HD1500E)
300W approx. (AC operation, including SK-HD1500 Power consumption
,VF-402 ,CA-HF1500 and AUX POWER OUT 100VA)
Operating：0℃ ～ +40℃
Ambient Temperature
Storage：-20℃ ～ +60℃
Dimensions 433(W)  88(H)  347(D) mm
Mass 10kg approx.
1km (Full operation) Maximum cable distance
4km (Without utility power)
■Input output signals (CU-HD1500)
Input signals
Camera Control Unit CU-HD1500 (INPUT)
GEN LOCK IN B-BST 0.45Vp-p/75Ω(loop through)
or HDTV tri-level sync 0.60Vp-p/75Ω
(loop through)
BNC x1
DIGITAL RET IN(A) 1/2/3/4
(B) 1/2
HD-SDI or SD-SDI
・1080i：SMPTE292M
・720p ：SMPTE292M
・SD-SDI : SMPTE259M-C
BNC x4 + x2
(A)x4：for VF
(B)x2：for floor monitor
PROMPT IN VS or VBS 1.0Vp-p/75Ω(loop through) BNC x1
INTERCOM(HEAD SET) -60dBm XLR-5pin(Female)
COMMUNICATION D-sub 15pin
・INTERCOM
0dBm , 600Ω at 4Wire
0dBu or -15dBu ,200Ω at 2Wire
Clear-Com and RTS compatible
PD/ENG
・PGM
0dBm/600Ω
・R/G TALLY
Contact or Voltage selectable
REMOTE 1 1.5Vp-p 4pin
REMOTE 2 1.5Vp-p 4pin
REMOTE 3 Remote RJ-45
TRUNK RS-422 (150k baud)
(RS-232C : Option)
D-Sub 9 pin
