Hitachi H8S/2646 User Manual

1118
Appendix F Package Dimensions
Figure F-1 shows the package dimensions of the H8S/2646R and H8S/2648R and figure F-2
shows that of the H8S/2646, H8S/2645, H8S/2648, and H8S/2647.
Hitachi Code
JEDEC
JEITA
Mass
(reference value)
FP-144J
−
Conforms
2.4 g
*Dimension including the plating thickness
Base material dimension
0.10
M
20
22.0 ± 0.2
73
36
144
0.5
0.10
3.05 Max
0° − 8°
22.0 ± 0.2
108
72
37
109
1
0.17 ± 0.05
2.70
0.22 ± 0.05
0.5 ± 0.1
1.0
0.10
+0.15 −0.10
1.25
0.20 ± 0.04
0.15 ± 0.04
*
*
Unit: mm
Figure F-1 FP-144J Package Dimension (H8S/2646R, H8S/2648R)
