270
9.10.4 MOS Input Pull-Up Function
Port C has a built-in MOS input pull-up function that can be controlled by software. This MOS
input pull-up function can be used in modes 6 and 7, and can be specified as on or off on an
individual bit basis.
In modes 6 and 7, when PCPCR is set to 1 in the input state by setting of the LCD driver LPCR
and PCDDR, the MOS input pull-up is set to ON.
The MOS input pull-up function is in the off state after a reset, and in hardware standby mode.
The prior state is retained by a manual reset or in software standby mode.
Table 9-21 summarizes the MOS input pull-up states.
Table 9-21 MOS Input Pull-Up States (Port C)
Pin States Reset
Hardware
Standby Mode
Software
Standby Mode
In Other
Operations
Address output OFF OFF OFF OFF
Other than above ON/OFF ON/OFF
Legend:
OFF: MOS input pull-up is always off.
ON/OFF: On when PCDDR = 0 and PCPCR = 1; otherwise off.
