534
Name Abbreviation R/W Initial Value Address* Access Size
Local acceptance filter mask L LAFML R/W H'0000 H'F81C 8/16 bits
Local acceptance filter mask H LAFMH R/W H'0000 H'F81E 8/16 bits
Message control 0 [1:8] MC0 [1:8] R/W Undefined H'F820 8/16 bits
Message control 1 [1:8] MC1 [1:8] R/W Undefined H'F828 8/16 bits
Message control 2 [1:8] MC2 [1:8] R/W Undefined H'F830 8/16 bits
Message control 3 [1:8] MC3 [1:8] R/W Undefined H'F838 8/16 bits
Message control 4 [1:8] MC4 [1:8] R/W Undefined H'F840 8/16 bits
Message control 5 [1:8] MC5 [1:8] R/W Undefined H'F848 8/16 bits
Message control 6 [1:8] MC6 [1:8] R/W Undefined H'F850 8/16 bits
Message control 7 [1:8] MC7 [1:8] R/W Undefined H'F858 8/16 bits
Message control 8 [1:8] MC8 [1:8] R/W Undefined H'F860 8/16 bits
Message control 9 [1:8] MC9 [1:8] R/W Undefined H'F868 8/16 bits
Message control 10 [1:8] MC10 [1:8] R/W Undefined H'F870 8/16 bits
Message control 11 [1:8] MC11 [1:8] R/W Undefined H'F878 8/16 bits
Message control 12 [1:8] MC12 [1:8] R/W Undefined H'F880 8/16 bits
Message control 13 [1:8] MC13 [1:8] R/W Undefined H'F888 8/16 bits
Message control 14 [1:8] MC14 [1:8] R/W Undefined H'F890 8/16 bits
Message control 15 [1:8] MC15 [1:8] R/W Undefined H'F898 8/16 bits
Message data 0 [1:8] MD0 [1:8] R/W Undefined H'F8B0 8/16 bits
Message data 1 [1:8] MD1 [1:8] R/W Undefined H'F8B8 8/16 bits
Message data 2 [1:8] MD2 [1:8] R/W Undefined H'F8C0 8/16 bits
Message data 3 [1:8] MD3 [1:8] R/W Undefined H'F8C8 8/16 bits
Message data 4 [1:8] MD4 [1:8] R/W Undefined H'F8D0 8/16 bits
Message data 5 [1:8] MD5 [1:8] R/W Undefined H'F8D8 8/16 bits
Message data 6 [1:8] MD6 [1:8] R/W Undefined H'F8E0 8/16 bits
Message data 7 [1:8] MD7 [1:8] R/W Undefined H'F8E8 8/16 bits
Message data 8 [1:8] MD8 [1:8] R/W Undefined H'F8F0 8/16 bits
Message data 9 [1:8] MD9 [1:8] R/W Undefined H'F8F8 8/16 bits
Message data 10 [1:8] MD10 [1:8] R/W Undefined H'F900 8/16 bits
Message data 11 [1:8] MD11 [1:8] R/W Undefined H'F908 8/16 bits
Message data 12 [1:8] MD12 [1:8] R/W Undefined H'F910 8/16 bits
Message data 13 [1:8] MD13 [1:8] R/W Undefined H'F918 8/16 bits
Message data 14 [1:8] MD14 [1:8] R/W Undefined H'F920 8/16 bits
Message data 15 [1:8] MD15 [1:8] R/W Undefined H'F928 8/16 bits
Module stop control
register C
MSTPCRC R/W H'FF H'FDEA 8/16 bits
Note: *Lower 16 bits of the address.
