●Creating a user pattern 7-25
4
Create user pattern 2015.07.0712:45
Com=0
[Stop ]
Pattern [ ]
Pattern size
Hor. ［ 32］
Vert.［ 16］
Cursor
position
Hor. ［ 9］
Vert.［ 12］
Zoom
×1
〈
《 》
〉
▲
△
▼
▽
Clear
Back
Select Save
Dupli-
cate
Paste Move
Clear
area
Invert
Rec-
tangle
Rec-
tangle
fill
Pat-
tern
paste
HOME
Startup
Manual
Create user pattern 2015.07.0712:45
Com=0
[Stop ]
Pattern [ ]
Dot matrix Free
Stored destination
pattern [002]
OK
Change Change
EB
Logo
★◎ ‥
Cancel
HOME
Startup
Manual
−
Create a pattern at the dot pattern creation area. When touched directly, the dot is
inverted.
5
Press Save .
The save screen is displayed.
6
Press OK .
The pattern is saved.
Scroll up
8 dots
1 dot
Scroll down
1 dot
8 dots
Clears the dots of
the pattern.
Save
When a dot was
reversed by
touching it directly,
make the display
magnification
quadruple.
Scroll rigth
> 1 dot
>> 8 dots
Draws a graphic. (See 7.3.3.)
Scroll left
<< 8 dots
< 1 dot
Inverts the dot
of the touched
position.
When the save
destination is
specified, the
save destination
code and pattern
are displayed.
Touch the position
on the keyboard to
be saved.
Press to display
the next screen.
OK
