●Save created messages 4-16
4.6 Save created messages
(1) Overview
●Saves created messages.
●A save No. is automatically assigned.
●The same message name cannot be assigned.
●Saving to a selected group is possible.
●Free spaces are displayed (ONLY Previews HMI screen).
Item Contents
Free space Proportional of save area which is vacant.
● If the number of input characters is small, the capacity necessary to save the message decreases. A lot of
small capacity messages can be saved. When there are many large capacity messages, the number of
messages which can be saved decreases.
Maximum message save count
Model type Maximum save count Remarks
UX-B 150 messages
150 messages can be saved without regard
to their capacity.
UX-D
300 messages
300 messages can be saved without regard
to their capacity.
Option :
Up to 2,000 messages
The save count depends on the capacity.
UX-E 2,000 messages
2,000 messages can be saved without
regard to their capacity.
*1) Maximum message save count
Conditions example Message save count
Characters 70 chars 2,000 messages
Characters 20 chars, calendar 1, count 1 Approx. 1,900 messages
Characters 240 chars Approx. 800 messages
Characters 240 chars, calendar 8, count 8 Approx. 300 messages
*1)
