12-13
Display
(Function mode 1) (Function mode 2)
Setting, change
sequence
Function Function Initialization display Initialization
contents
Setting contents
No. name contents
30 F-37 Monitor MONITOR A-F A-F A-F/A/T/D-F • The FM terminal monitor
signal signal output is selected.
selection A-F: Analog frequency
T: Torque monitor
A: Current monitor
D-F: Digital frequency
31 F-38 Trip history INIT TCNT CNT CNT CNT/CLR • Trip count deletion selection
Initiali- count clear CNT: Trip counting is
zation continued.
CLR: The trip count is
cleared.
Debug INIT DEBG OFF OFF ON/OFF • Debug mode setting ON or
mode OFF
display OFF: The debug mode is
selection turned off.
NOTE 1 ON: The debug mode is
turned
on.
Digital INIT DOPE FWD FWD FWD/REV • The digital operator running
operator direction is set.
rotation FWD: Forward run
direction REV: Reverse run
selection
Selection of INIT RESET ON ON ON/OFF ON: Alarm release when reset
reset on
performance
OFF:Alarm release when reset
off
32 F-39 Encode OP P 01024 pulse 1024 255 to 65535 Effective with option board
Option pulse (J-FB)
setting number
setting
Control OP MODE ASR ASR ASR/APR
mode
selection
Ro-To OP RO-TO OFF OFF OFF/ON Keep OFF. (No use)
option
selection
33 F-40 Stop OR POS IN IN IN/OUT Effective with option board
Orientation position (J-FB)
setting setting
switching
Stop OR P 00000 pulse 0 0 to 4095
position
setting
Speed setting
OR FC 0005.0 Hz 5.0 Hz 0 to 400 Hz
Direction OR TURN FWD FWD FWD/REV
setting
Completion OR L 00005 pulse 5 0 to 10000
range setting
Completion OR TW 0.00 s 0 0 to 9.99
delay time
setting
NOTE 1 : Keep debug mode " OFF " , this is factory use only.
