A-4
Display when the autotuning terminates
[Display in the normal state]
• When the autotuning terminates normally, the following is displayed. When one of the keys is
pressed, the original screen is displayed.
•Digital operator
•Remote operator
•New remote operator
[Display in the failure state]
• If the autotuning is executed when the motor is not connected to the inverter, the following is dis-
played and the measurement is stopped. As a motor constant when the measurement fails, the last
value is set. When one of the keys is pressed, the original screen is displayed. When executing the
measurement once again, change the autotuning measurement setting to “Start” and enter the run
command in the same way.
•Digital operator
•Remote operator
•New remote operator
When running the inverter using the autotuning data after the autotuning measurement terminates,
make settings by the method indicated on the next page.
➤
Normal termination display
Normal termination display
OK Function 3 OR FR
Tuning END
➤
Abnormal termination display
Tuning NG
NG Function 3 OR FR
Abnormal termination display
To Next Page
