7-3
7.4 Explanation of Screen Display
• When the inverter is turned on, the latest display appears. However, when the display
unit for data of the commands F2 to F14 is turned off, the commands (F2 to F14) are
displayed. (d10 and d11 excluded)
• Data during running in any function mode or extension function mode can be displayed.
Even if data cannot be changed during running, data can be monitored.
• In each of the function modes , , , , and , data
can be changed even during running. In other function modes and extension function
modes, data cannot be set during running.
Or data display
RUN
.
➤
➤
to to
FUNC
,
Running start
The display is left unchanged.
Data can be changed
even during running
Code which can change data during running
