3.5. COMBINATION TABLE FOR MULTIZONE OUTDOOR
3.5.1. RAM-40NE2F
Whichever indoor units are installed, cooling and heating capacity depends on how many and which indoor units are operating at
the same time.
[1] Capacity loss due to white frost and defrost operation is not included.
POSSIBLE
COMBINATIONS
TO OPERATE
COOLING HEATING
TOTAL
(kW)
CAPACITY
RATING(kW) (RANGE)
OUTDOOR UNIT
EER
CAPACITY
RATING(kW)
(RANGE)
OUTDOOR UNIT
COP
TOTAL
INPUT
(W)
AMPERE(A)
TOTAL
INPUT
(W)
AMPERE(A)
TOTAL 220V
230V
240V
TOTAL
[1]
220V
230V
240V
ONE UNIT
1.5 1.5 1.50 1.50 380 1.74 1.67 1.60 3.95 2.00 2.00 530 2.43 2.33 2.23 3.77
(1.00-2.20) (250-480) (1.10-3.20) (250-970)
1.8 1.8 1.80 1.80 455 2.09 2.00 1.91 3.96 2.50 2.50 690 3.17 3.03 2.90 3.62
(1.00-2.50) (250-750) (1.10-3.20) (250-1000)
2.5 2.5 2.50 2.50 600 2.8 2.6 2.5 4.17 3.50 3.50 990 4.55 4.35 4.17 3.54
(1.00-3.10) (250-880) (1.10-4.40) (250-1200)
3.5 3.5 3.50 3.50 800 3.7 3.5 3.4 4.38 4.80 4.80 1350 6.2 5.9 5.7 3.56
(1.00-4.00) (250-950) (1.10-5.00) (250-1550)
TWO UNITS
1.5+1.5 3.0 1.50+1.50 3.00 850 3.9 3.7 3.6 3.53 2.00+2.00 4.00 1000 4.6 4.4 4.2 4.00
(1.50-3.50) (250-1100) (1.50-4.60) (250-950)
1.5+1.8 3.3 1.50+1.80 3.30 920 4.2 4.0 3.9 3.59 2.00+2.50 4.50 1210 5.6 5.3 5.1 3.72
(1.50-3.50) (250-1200) (1.50-5.00) (250-1020)
1.5+2.5 4.0 1.50+2.50 4.00 1026 4.7 4.5 4.3 3.90 1.85+3.25 5.10 1243 5.7 5.5 5.2 4.10
(1.50-4.40) (250-1270) (1.50-5.50) (250-1700)
1.5+3.5 5.0 1.20+2.80 4.00 1150 5.3 5.1 4.8 3.48 1.50+3.60 5.10 1250 5.7 5.5 5.3 4.08
(1.50-4.40) (250-1270) (1.50-5.50) (250-1700)
1.8+1.8 3.6 1.80+1.80 3.60 970 4.5 4.3 4.1 3.71 2.50+2.50 5.00 1190 5.5 5.2 5.0 4.20
(1.50-4.40) (250-1270) (1.50-5.00) (250-1700)
1.8+2.5 4.3 1.67+2.33 4.00 1100 5.1 4.8 4.6 3.64 2.13+2.98 5.10 1250 5.7 5.5 5.3 4.08
(1.50-4.40) (250-1270) (1.50-5.50) (250-1700)
1.8+3.5 5.3 1.36+2.64 4.00 1150 5.3 5.1 4.8 3.48 1.75+3.35 5.10 1250 5.7 5.5 5.3 4.08
(1.50-4.40) (250-1270) (1.50-5.50) (250-1700)
2.5+2.5 5.0 2.00+2.00 4.00 1150 5.3 5.1 4.8 3.48 2.55+2.55 5.10 1250 5.7 5.5 5.3 4.08
(1.50-4.40) (250-1270) (1.50-5.50) (250-1700)
2.5+3.5 6.0 1.67+2.33 4.00 1190 5.5 5.2 5.0 3.36 2.15+2.95 5.10 1300 6.0 5.7 5.5 3.92
(1.50-4.40) (250-1270) (1.50-5.50) (250-1700)
