Chapter 7 Explanation of Functions
7 - 48
7.6.11 Function code display restriction [b037]
The function code display restriction function allows you to arbitrarily switch the display mode or the
display content on the digital operator.
Item Function code Data Description
Function code display restriction b037
00 Full display
01 Function-specific display
03 Data comparison display
04 Basic display
05 Monitor mode (d***) only
(1) Function-specific display mode
If a specific function has not been selected, the monitor does not display the parameters concerning the
specific function.
The following table lists the details of display conditions:
No. Display condition Parameter displayed when the display condition is met
1 One of C001 to C005 = 08
F202, F203, A201 to A204, A220, A241 to A247, A261,
A262, A281, A282, A292 to A296, b212, b213, b221 to
b223, C241, H203, H204 and H206
2
A044 = 02 or/ One of C001 to C005 = 08 and
A244 = 02
b100 to b113
3
b013 = 02 or/ One of C001 to C005 = 08 and
b213 = 02
b015 to b020
4 A044 = 00 or 01 A041 to A043, A046, A047
5 One of C001 to C008 = 08 and A244 = 00, 01 A241 to A243, A246, A247
6 A051 = 01, 02 or/ One of C001 to C005 = 06, 07 A052 to A059
7 A071 = 01, 02 d004, A072 to A079, A156 to A158, C044, C052, C053
8 A097, A098 = 01 to 03 A131, A132
9 b050 = 01 to 03 b051 to b054, b134, b135
10 b130 = 01 to 03 b131 to b134
11 C070 = 01 C071 to C078
(2) Data comparison display mode
The monitor displays only the parameters that have been changed from the factory settings, except all
monitoring indications (d***) and code "F001".
To Next Page
