Page #14 background image
Chapter 1 Safety Instructions
1 - 5
1.2 Precautions Concerning Electromagnetic Compatibility (EMC)
CE-EMC Installation Guidelines
You are required to satisfy the EMC directive (2004/108/EC) when using a NE-S1 inverter in an EU
country.
To satisfy the EMC directive and to comply with standard, you need to use a dedicated EMC filter suitable
for each model, and follow the guidelines in this section. Following table shows the compliance condition
for reference.
Table 1. Condition for the compliance
Model Cat. Carrier f Motor cable
1-ph. 200V class C2 2kHz 20m (Shielded)
3-ph. 200V class C3 2kHz 20m (Shielded)
3-ph. 400V class C3 2kHz 20m (Shielded)
Table 2. Applicable EMC filter
Input class Inverter model Filter model (Schaffner)
1-ph. 200V class
NES1-002SB
FS24828-8-07
NES1-004SB
NES1-007SB
FS24828-27-07
NES1-015SB
NES1-022SB
3-ph. 200V class
NES1-002LB
FS24829-8-07
NES1-004LB
NES1-007LB
NES1-015LB
FS24829-16-07
NES1-022LB
3-ph. 400V class
NES1-004HB
FS24830-6-07
NES1-007HB
NES1-015HB
FS24830-12-07
NES1-022HB
NES1-040HB
