Hitachi NES1-004SB User Manual

Chapter 3 Exterior Views
3 - 1
*)002-007SB/LB and 004HB : without Cooling Fan
3.1 Exterior Views and Names of Parts
The figure below shows an exterior view of the inverter
- model : NES1 – 002*,004*SB/LB , 007*LB
- model : NES1 – 007*SB , 015,022SB , 004*,007,015,022HB,040HB
a) Cooling Fan Cover d) Case
b) Cooling Fan e) Front Cover
c) Heat sink f) Backing plate
W
D
H
W
D
H
c
d
e
f
c
d
e
f
b
a

Hitachi NES1-004SB Specifications

General

Brand	Hitachi
Model	NES1-004SB
Category	Inverter
Language	English
