7.4.5 Start/end frequency setting for external analog input
The start/end frequency setting function allows you to set the inverter output frequency in relation to the
external analog inputs (frequency commands) via the following terminals:
- O/OI-L terminal: 0 to 10 V or 0 to 20mA
- VR : volume of NES1-OP, OPE-SR/SRmini
(1) Start/end frequency settings for the O/OI-L terminals
Item
Function
code
Range of data Description
[O/OI]-[L] input /VR active
range start frequency
A011/A161
0.00 to
400.0(Hz)
Setting of the start frequency
[O/OI]-[L] input /VR active
range end frequency
A012/A162
0.00 to
400.0(Hz)
Setting of the end frequency
[O/OI]-[L] input /VR active
ran
g
e start volta
g
e
A013/A163 0. to 100.(%)
Setting of the rate of the start frequency to the
external frequenc
y
command
(
0 to 10 V/0 to 20 mA
)
[O/OI]-[L] input /VR active
ran
g
e end volta
g
e
A014/A164 0. to 100.(%)
Setting of the rate of the end frequency to the
external frequenc
y
command
(
0 to 10 V/0 to 20 mA
)
[O]/[OI]-[L] input start
frequency enable
A015/A165
00
Externally input start frequency
The frequency set as "A011/A161" is output as the
output frequency while the start-frequency rate is 0%
to the value set as "A013
/
A163".
01
0 Hz
0 Hz is output as the output frequency while the
start-frequency rate is 0% to the value set as
"A013
/
A163".
If the voltage of the signal to be input to the O-L terminal is 0 to 5 V, specify 50% for "A014".
(Example 1) A015: 00 (Example 2) A015: 01
Out put frequency in
the range from 0% to
A013 is A011
A
012
A
011
0
A
013
A
014 100
(0 V/0 mA) (10 V/20 mA)
(O/OI)
Maximum
frequency
Analog input
Out put frequency in
the range from 0% to
A013 is 0Hz
Maximum
frequency
Analog input
A
012
A
011
0
A
013
A
014 100
(0 V/0 mA) (10 V/20 mA)
(O/OI)
