Chapter 5 Wiring
5 - 16
(2)
Souce logic
P24
PLC
L
1
P24
PLC
L
1
SW OFF
Power-ON
Power-OFF
Input
ON
P24
PLC
L
1
P24
PLC
L
1
SW OFF
Power-OFF
short circuit bar
short
circuit bar
Power-ON
Input
OFF
The input is recognized
as ON in spite of OFF without Diode.
Providing a diode instead of the short circuit
bar, so that the current flowing is prevented.
Additional diode
