5 - 6
(c) Put on safety goggles for the subsequent steps.
(d) Detach the connector between lamp house and main
body, and loosen the lamp house retaining screw.
Fig. 5-2 Removal of Connector and Retaining Screw
(e) Lift the grip of the lamp house lightly and pull it toward
you, then detach the lamp house from the main body.
Fig. 5-3 Removal of Lamp House
To Next Page
