Hitachi RX - Page 50

●Setting Communication Environment 5-4
Comm. env. setup 2015.07.0712:45
Back
Com=0
[Stop ]
State at power-up
Communication and signal error
＜Transmission condition by port＞
Target port
Baud rate (bps)
＜Data format＞
Data length
Parity bit
Stop bits
＜Standard communication＞
Number of comm. bytes
BCC code handling
Communication mode
Print message transfer ACK
Print spec transfer char height
Comm. port in ON
Disable
4800
M
Manual
Startup
HOME
Prev.Dsp.
NextDsp.
Warn.
Fault
1 bits
2 bits
1 byte
2 bytes
Disable
Enable
2 digits
3 digits
8 bits
7 bits
Standard port
overwrite-protected
overwrite-enabled
t=async.
t=fixed
Changetheon-line
oroff-line.
Comm. env. setup 2015.07.0712:45
Back
Com=0
[Stop ]
Buffer function
Buffer repeat count
Empty Buffer Fault
Timing of Fault
Data Number at Fault
Prev.Dsp.
NextDsp.
0
(0〜9)
(1〜9999)
M
Manual
Startup
HOME
Disable
Enable
０００１
Settingofcommunicationbuffer
(Referto"5.9Communicationbuffer".)
Disable
Enable
Print Start
Print. Complete
(2) Operating procedure
Press Communication environment setup from the Environment setup menu.
The "Communication environment setup" screen appears.
1
Press Next settings .
The second screen appears.
2
