●Code tables 5-42
Type Header Classification
Data
count
Data section
Recall Message number 20H 31H 4 0001 to 2000
Registration
Message number
21H
31H 4 0001 to 2000
Message name 32H 1 to 12 Message name: Max 12 digits
Print format
Line count, print format
uniformity
22H
31H 0 -
Line count/Line spacing 32H 2
Line count : 1 to 5
Line spacing: 0 to 2
Character size/
inter character space
23H
31H 3
Character size : 30H to 3CH
Inter character space : 00 to 28
Increased width 32H 1 1 to 9
Bar code 33H 1 30H to 44H
Readable code 34H 1 0 to 2
Prefix Code 35H 2 00 to 99
Print
specifications
Character height
25H
31H 2 00 to 99
Ink drop use percentage 32H 2 01 to 16
High-speed printing 33H 1 0 to 2
Character width 34H 4 0000 to 3999
Character orientation 35H 1 0 to 3
Print start delay 36H 4 0000 to 9999
Print start delay (reverse) 37H 4 0000 to 9999
Product speed matching 38H 1 0 to 1
Pulse rate division Factor 39H 3 001 to 999
Repeat count 3DH 4 0000 to 9999
Repeat intervals 3EH 5 00000 to 99999
Target sensor timer 3FH 3 000 to 999
Target sensor filter 40H 1 1 to 2
Target sensor filter value 41H 4 0000 to 9999
Calendar
condition
Offset
(Year / month / day / hour /
minute)
28H
32H 6
Calendar block : 1 to 8
Type : 0 to 4
Offset : Yaer 0000 to 0099
Month 0000 to 0099
Day 0000 to 1999
Hour -023 to 0099
Minute -059 to 0099
Zero suppress usage
(Year / month / day / hour /
minute / week /
Day of week)
34H 3
Calendar block : 1 to 8
Type : 0 to 6
Mode : 0 to 2
5.4.2 Header Table
ESC2 Header Classification
