Hitachi SJ200 Series

Inverter MODBUS RTU Driver
GP-Pro EX Device/PLC Connection Manual
18
 External Device Settings
To define the External Device communication settings, use the External Device keypad’s STOP/RESET, ESC,
Up, Down, and SET keys.
Refer to your External Device manual for details.
1 Turn ON the External Device.
2 Press STOP/RESET to stop operations.
3 Press ESC to move to the Function Group.
4 Press ESC to select [C001].
5 Press Up or Down to select the function code.
6 Press SET.
7 Press Up or Down to select the value.
8 Press SET.
9 Restart the External Device.
 Setting Value
Function Code Setting Value Setup Description
C071 06 Communication speed (19200bps)
C072 1 Modbus address (Modbus slave address)
C074 00 Communication parity (Non-Parity)
C075 1 Communication stop bit (1 bit)
C096 00 Communication selection (Modbus-RTU)
