Holding Register data configuration (6/13)
Word
address
Classification Item name Setting range Contents
1A C0
Substitution
rule
Substitution rules No. 1 to 99
Substitution rules will be registered
with the specified Substitution
rules number, Start year and
Substitution rules setup items.
1A C1 Starting year 2000 to 2099
1A C2 Substitution character(Year) 0x0020 to 0xFFFF
… … …
1A F3 Substitution character(Year) 0x0020 to 0xFFFF
1A F4 Substitution character(Month) 0x0020 to 0xFFFF
… … …
1B 17 Substitution character(Month) 0x0020 to 0xFFFF
1B 18 Substitution character(Day) 0x0020 to 0xFFFF
… … …
1B 74 Substitution character(Day) 0x0020 to 0xFFFF
1B 75 Substitution character(Hour) 0x0020 to 0xFFFF
… … …
1B A4 Substitution character(Hour) 0x0020 to 0xFFFF
1B A5 Substitution character(Minute) 0x0020 to 0xFFFF
… … …
1C 1C Substitution character(Minute) 0x0020 to 0xFFFF
1C 1D
Substitution character
(Week number)
0x0020 to 0xFFFF
… … …
1C BB
Substitution character
(Week number)
0x0020 to 0xFFFF
1C BC
Substitution character
(Day of week)
0x0020 to 0xFFFF
… … …
1C D0
Substitution character
(Day of week)
0x0020 to 0xFFFF
1C D1 Reserve_1
-
"Reserve" is not initially provided,
but may be added in future.
… …
1C D3 Reserve_3
1C D4
Time count
condition
Range (Lower limit)
(1st digit)
0x0020 to 0xFFFF
Sets the range (Lower limit).
… … …
1C D6
Range (Lower limit)
(3rd digit)
0x0020 to 0xFFFF
1C D7
Range (Upper limit)
(1st digit)
0x0020 to 0xFFFF
Sets the range (Upper limit).
… … …
1C D9
Range (Upper limit)
(3rd digit)
0x0020 to 0xFFFF
1C DA Reset(1st digit) 0x0020 to 0xFFFF
Sets the reset.
… … …
1C DC Reset(3rd digit) 0x0020 to 0xFFFF
1C DD Reset time 0 to 23 Sets the reset time.
1C DE Renewal period 0 to 5
Sets the renewal period.
0:5 minutes, 1:6 minutes
2:10
minutes, 3:15 minutes
4:20
minutes, 5:30 minutes
1C DF Reserve_1 -
"Reserve" is not initially provided,
but may be added in future.
To Next Page
