WL200 Inverter Specifications, continued…
General Specifications
Protection structure Note 4)
Line-to-line sinusoidal PWM method
Output frequency range Note 5)
Frequency accuracy Note 6)
For maximum frequency, digital command ±0.01%, analog command
±0.2%(25±10℃)
Frequency setting resolution
Digital setting: 0.01Hz Analog setting: Maximum frequency/1000
Voltage/Frequency characteristic
V/f characteristic (Constant torque, Reduced torque, Free V/f)
120%/ 1 minute and 140%/ 12seconds
Acceleration/Deceleration time
0.00 to 3600 seconds (Linear, Curve optional setting).
Second acceleration/deceleration setting available.
Operates when frequency became lower than deceleration frequency
by stop command, or when frequency became lower than setting
frequency at running, or by external input (level and time setting
available).
Agaist overcurrent, overvoltage, undervoltage, electronic thermal,
abnormal temperature, earth fault overcurrent when powered on,
overload, over receive voltage, external trip, memory error, CPU error,
USP error, communication error, overvoltage suppression at
deceleration, momentary electric outage, emergency interrupt, etc.
Digital/Remote operator External Analog input signal: Variable
resistor/ DC0 to 10V / 4 to 20mA, Modbus communication
Digital/Remote operator
External digital signal (3 wire input available), Modbus communication
7 points (1, 2, 3/GS1, 4/GS2, 5/PTC, 6, 7/EB)
2 points (Voltage O terminal: 10bit/0 to 10V, Current OI terminal:
10bit/0 to 20mA)
1 point (1c contact point (AL0, AL1, AL2))
1 point (AM terminal: 10bit/0 to 10V)
1 point (EO terminal: 32kHz(10V))
RJ45 connector, Operator use
Control circuit terminal stage, Modbus
AVR function, V/f characteristic switching, Upper/Lower limitter, 16 stage multi speed, Starting frequency
adjustment, Jogging operation, Carrier frequency adjustment, PID control, Frequency jump, Analog-in bias
adjustment, S-type acceleration.deceleratio, Electronic thermal chracteristic/Level adjustment, Retry
function, Torque boost function, Trip monitor, Soft lock function, Frequency conversion display, USP
function, Second control function, UP/DOWN, Overcurrent suppress function, etc.
-10 to 40℃ (Derating is required) (Refer to the instruction manual)
-20 to 65℃ (Short time temperature during transportation)
5.9m/s
2
(0.6G), 10 to 55Hz
Altitude lower than 1,000m, In-door (No corrosive gas, no dust)
No painting,[Mold: Black(Munsell N1.5)]
UL, CE, C-UL, C-tick, Safety Note 7)
Noise filter, DC Reactor, AC Reactor, Remote operator, Connector
cable, Regenerative break unit, and Resistor, etc.
Note 1) Applicable motor is reference motor. When select motors, take notice so that rated current of motor
does not exceed over the inverter’s rated current.
Note 2) Output voltage decreases when power supply voltage is decreased.
Note 3) Control torque at capacitor feeding back is an average deceleration torque at the time of shortest
deceleration in motor unit (when stopped from 50Hz), not a continuous regenerated torque. Average
deceleration torque changes depending on motor loss. When operated exceeding over 50Hz, this
value is decreased.
