Hitachi WL200 Series Basic Manual

6
Fuse Sizes
Distribution fuse size marking is included in the manual to indicate that the unit shall be
connected with a Listed Cartridge Nonrenewable fuse, rated 600 Vac with the current
ratings as shown in the table below or Type E Combination Motor Controller marking is
included in the manual to indicate that the unit shall be connected with, LS Industrial
System Co.,Ltd,Type E Combination Motor Controller MMS Series with the ratings as
shown in the table below:
Inverter Model
Fuse
Inverse Time
Circuit Breaker
Type E CMC
Type
Rating
(Maximum A)
Rating
(Maximum A)
WL200-002S
WL200-004S
WL200-007S
Class J,
Class CC,
Class G,
Class T
10A, AIC 200kA
30A
MMS-32H,
240V,40A
WL200-015S
20A, AIC 200kA
WL200-022S
30A, AIC 200kA
WL200-004H
WL200-007H
WL200-015H
WL200-022H
10A, AIC 200kA
20A
MMS-32H,
480V,40A
or
MMS-63H,
480V,52A
WL200-030H
WL200-040H
WL200-055H
15A, AIC 200kA
WL200-075H
30A, AIC 200kA
40A
WL200-110H
WL200-150H
WL200-185H
50A, AIC 200kA
