Miscellaneous—Storage
OUT1739,0000258 –19–16JUN06–1/1
Prepare Machine for Storage
T47764 –UN–09NOV88
T5813AM –UN–09FEB89
1. Repair worn or damaged parts. Install new parts, if
necessary, to avoid needless delays later.
2. Clean primary air cleaner.
IMPORTANT: High pressure washing greater than
1379 kPa (13.8 bar) (200 psi) can
damage freshly painted finishes. Paint
should be allowed to air dry for 30 days
minimum after receipt of machine
before cleaning parts or machines with
high pressure. Use low pressure wash
operations until 30 days have elapsed.
3. Wash the machine. Use low pressure wash operations
(less than 1379 kPa (13.8 bar) (200 psi) until 30 days
after receipt of machine have elapsed. Paint areas to
prevent rust. Replace decals, where needed.
4. Apply waste oil to track chains. Run machine back and
forth several times. Park machine on a hard surface to
prevent tracks from freezing to ground.
5. Store machine in a dry, protected place. If stored
outside, cover with a waterproof material.
IMPORTANT: LPS 3 Rust Inhibitor can destroy
painted finish. DO NOT spray LPS 3
Rust Inhibitor on painted areas.
6. Retract all hydraulic cylinders, if possible. If not, coat
exposed cylinder rods with LPS

3 Rust Inhibitor.
7. Place a "DO NOT OPERATE" tag on the right control
lever.
8. Lubricate all grease points.
9. Remove batteries.
10. Remove seat cushion and other perishable items.
11. Remove keys and lock all covers and doors.
LPS is a trademark of the Holt Lloyd Corporation.
4-4-1 081407
PN=197
