PROGRAM SELECT(01)
Mode: Discharge
C.Current OFF
D. Current -2.0A
Operating the Charger (continued)
C. Current (Charge Current)
The charger supports a maximum 6.0A
charge current, but a current suitable for your
battery should be set. It is inappropriate to
set a high charge current for a low capacity
battery, as doing so would result in unwanted
consequences.
*NOTE: This mode is only available under the
Charge mode
D. Current (Discharge Current)
The charger supports a maximum -2.0A dis-
charge current, but users should set the appro-
priate discharge current for the battery in use.
* Note that this mode is only available under the
Discharge mode.
Target Volt - (Target Voltage)
This function is available when working with-
Lithium and Lead Acid (Pb) chemistry batteries.
Here you can set the target voltage for each
individual cell.
WARNING: Setting the target voltage too high
can damage your battery and cause your bat-
tery to explode. See the packs manufacturer’s
recommended settings before changing this
value from the defaults.
Cut Volt - (Cutt-o Voltage)
This function can be activated under Discharge
mode no matter the type of batteries being
discharged. This function protects a battery
from deep discharging. Refer to the chart on
page 6 for recommended cut-o voltage.
PROGRAM SELECT(01)
C. Current 3.3A
D. Current OFF
Target Volt: 4.20V
Cut Volt: OFF
PROGRAM SELECT(01)
Battery Type: LiPo
Battery Cells: 3S
Mode: Balance
C. Current 3.3A
Battery Cells: 3S
PROGRAM SELECT(01)
C. Current 3.3A
D. Current OFF
Target Volt: 4.20V
Cut Volt: OFF
To Next Page
