PROGRAM SELECT(01)
Battery Type: LiPo
Battery Cells: 3S
Mode: Balance
C Current 3.3A
BATT/PROGRAM Select
Press INC and DEC to cycle through all battery
types and press START/ENTER to select the
appropriate battery types to be charged.
Battery Cells
Press INC and DEC to scroll through the
battery cells supported by the charger. Press
START/ENTER to select the appropriate cells for
your battery.
Mode Select
Press INC and DEC to scroll through all
available modes. If you plan to charge your
battery, select Charge mode. Press the START/
ENTER button to conrm the mode of your
choice.
The following is a step-by-step guide for operating the RDX1. The screen shots
and operation templates shown below are for the operation of a Li-Po BAL-
ANCE CHARGE program . Refer to the Available Operations chart on page 13
and 14 to setup your specic type of battery.
Whenever a parameter value in the program needs to be adjusted, highlight
the value by pressing the START/Enter button to make it blink; to change the
value press the DEC or INC buttons. The new value will be stored by re-press-
ing the START/Enter button. If there is another parameter to be adjusted as
part of a range on the same screen, it will start blinking after the rst param-
eter value has been conrmed.
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SAFETY
INFORMATION CONTAINED ON PAGES 37.
Warning
PROGRAM SELECT(01)
Battery Type: LiPo
Battery Cells: 3S
Mode: Balance
C Current 3.3A
PROGRAM SELECT(01)
Battery Type: LiPo
Battery Cells: 3S
Mode: Balance
C Current 3.3A
Operating the Charger
*NOTE: WHEN IN IDLE MODE, BACKLIGHT TURNS OFF
