From the main menu, press the scroll button to enter the Charger’s settings.
LITHIUM PROGRAM (LiPo/LiFe/Lilo/LiHV)
Battery Type
Condition
Battery Cell
Task
Start
Back
CHARGE SETTING
LiPo
4.2V
6S(22.2V)
Balance CHG
CH A
Current 10.0A
1 2

Using the scroll wheel, select the
type of battery connected.

Using the scroll wheel, select the
cell count of the battery connected.
Press scroll wheel
to confirm.
Press scroll wheel
to confirm.
Battery Type
LiPo
Lilo
LiFe
LiHV
NiMH
NiCd
Battery Cell
1S (3.7V)
2S (7.4V)
3S (11.1V)
4S (14.8V)
5S (18.5V)
6S (22.2V)
3

Using the scroll wheel, select the charge
mode. LiPo Balance is recommended.
Press scroll wheel
to confirm.
Task
Balance CHG
Charge
Storage
Discharge
4

Using the scroll wheel, select the end voltage.
The default is 4.20V, recommended to skip.
Press scroll wheel
to confirm.
Condition
4.18V
4.19V
4.19V
4.20V
4.21V
4.22V
5 6
 
Using the scroll wheel, select the charge
current. 1C charge rate is recommended.

Using the scroll wheel, select Start
and press to initiate the charge
process using the selected settings.
(IE 500mAh = 5.0A)
Press scroll wheel
to confirm.
Press the scroll button again to stop the
charge process and return to settings.
Current
0.1A
20.0A
0.2A
19.9A
Start
NiMH/NiCd PROGRAM
From the main menu, press the scroll button to enter the Charger’s settings.
1

Using the scroll wheel, select the
type of battery connected.
Press scroll wheel
to confirm.
Battery Type
LiPo
Lilo
LiFe
LiHV
NiMH
NiCd
Pb
2

Using the scroll wheel, select the
cell count of the battery connected.
Press scroll wheel
to confirm.
Battery Cell
3

Using the scroll wheel, select the charge
mode. LiPo Balance is recommended.
Press scroll wheel
to confirm.
Task
Charge
Re-Peak
CYCLE_C_D
CYCLE_D_C
4

Using the scroll wheel, select the delta voltage.
The default is -6mV, recommended to skip.
Press scroll wheel
to confirm.
Condition
-3mV
-4mV
-5mV
-6mV
-7mV
-8mV
-9mV
5
 
Using the scroll wheel, select the charge current.
1C charge rate is recommended.
(IE 500mAh = 5.0A)
Press scroll wheel
to confirm.
Current
0.1A
20.0A
0.2A
19.9A
6

Using the scroll wheel, select Start
and press to initiate the charge
process using the selected settings.
Press the scroll button again to stop the
charge process and return to settings.
Start
4S
14S
5S
15S
