HITEC RDX2 200 - Charger Layout; Charger Specifications

8 9
USB-C PD3.0 PC
INTERFACE PORT
PORT SELECT
METAL SCROLL WHEEL
SMART VENTILATION FAN
LCD DISPLAY
SCREEN
CHARGING PORTBALANCE PORT
DC INPUT 10-30V AC INPUT 100-240V
INPUT VOLTAGE
AC 100-240V (50/60Hz)
DC 10.0–30.0V
INPUT CURRENT DC 18.0A
CHARGE POWER
AC 100W/port MAX; 100W Total | PD3.0: 20W MAX
DC 100W/port MAX; 200W Total | PD3.0: 20W MAX
DISCHARGE POWER
MAIN PORT 5W/port
MAIN PORT + BALANCE PORT 30W MAX (LiPo/6S)
CHARGE CURRENT LiPo/LiFe/LiIo/LiHV/NiMH/NiCd/Pb 0.2-10.0A
DISCHARGE CURRENT LiPo/LiFe/LiIo/LiHV/NiMH/NiCd/Pb 0.1-2.0A
BALANCE CURRENT LiPo/LiFe/LiIo/LiHV 1000mA MAX
TRICKLE CURRENT NiMH/NiCd 50–300mA & OFF
BATTERY TYPES
LiPo/LiFe/LiIo/LiHV 1-6S
NiMH/NiCd 1-15S
Pb 3S/6S/12S
WORKING MODES
LiPo/LiFe/LiIo/LiHV Balance CHG, Charge, Discharge, Storage
NiMH/NiCd
Charge, Discharge, Re-peak, CYCLE_D_C, CYCLE_C_D
Pb Normal, AGM Charge, Cold Charge, Discharge
DC POWER SUPPLY
VOLTAGE 5.0–27.0V
CURRENT 1.0–10.0A
USB TYPE-C OUTPUT
QC3.0 5V 3A, 9V 2A, 12V 1.5A | 18W
PD 5V 3A, 9V 2.2A, 12V 1.67A | 20W
WORKING ENVR. — 32°F–104°F | 10%–80% Humidity
STORAGE ENVR. — 14°F–140°F | 20%–70% Humidity
SIZE — 4.6 x 4.3 x 3.1 in
NET WEIGHT — 1.3 lbs.
CHARGER LAYOUT CHARGER SPECIFICATIONS
