After connecting the battery, you are now ready to setup the charger to charge your specific type
of battery. When the charger is first powered on, the last program selected will be displayed.
If this is not the battery you plan on working with, then you will need to make changes to the
operation programming based on the following instruction.
BEFORE SELECTING AN OPERATION, IT IS CRITICAL THAT YOU KNOW THE TYPE
OF BATTERY YOU ARE WORKING WITH AND WHAT THE MANUFACTURER
RECOMMENDATIONS ARE FOR CHARGING OR DISCHARGING. FAILURE TO
FOLLOW THE MANUFACTURER'S RECOMMENDATIONS CAN RESULT IN DAMAGE
TO THE BATTERY AND CREATE AN EXPLOSION HAZARD.

Depending on battery type, dierent operations will be available. This chart shows which opera-
tions are available for the dierent types of batteries the RDX2 800 is capable of working with.
BATTERY OPERATION 
LiPo
Lilo
LiFe
LiHV
Balance CHG
This mode is to balance charge the lithium battery based on the charging rate. It
can balance each cell of the battery.
Charge This mode is to charge the lithium battery based on the charging rate selected.
Storage
This mode is to store the battery via charging or discharging its voltage to a
specific storage value.
Discharge
This mode is to discharge the lithium battery based on the discharging rate
selected.
Parallel This mode is to parallel charge the battery with a higher charge rate of up to 35.0A.
Cycle
This mode is to cycle discharge > charge the lithium battery to get the maximum
power of the battery. It's only available under the Balance CHG & Parallel charge
mode for the lithium battery.
NiMH
NiCd
Charge This mode is to charge the NiMH/NiCd battery based on the charging rate selected.
Re-Peak
In re-peak charge mode, the charger can peak charge the battery twice in a row
automatically. This is good for confirming the battery is fully charged, and for
checking how well the battery receives fast charges.
Cycle_C_D
Select 1 to 5 continuous charge>discharge cycles to refresh and restore
the performance of NiMH/NiCd batteries.
Cycle_D_C
Select 1 to 5 continuous discharge>charge cycles to refresh and restore
the performance of NiMH/NiCd batteries.
Discharge
This mode is to discharge the NiMH/NiCd battery based on the discharging
rate selected.
LEAD
ACID
Pb
Normal This mode is to charge the Pb battery based on the charging rate selected.
AGM Charge This mode is to charge the AGM battery based on the charging rate selected.
Cold Charge
This mode is to charge the Pb battery under a low temperature based on the
charging rate selected.
Discharge This mode is to discharge the Pb battery based on the discharging rate selected.
CHARGER OPERATION
WARNING
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU HAVE READ
AND UNDERSTOOD ALL OF THE WARNINGS AND SAFETY INFORMATION
CONTAINED IN THIS ENTIRE MANUAL.
WARNING
