HMS Anybus CompactCom 30 User Manual

Network Specific — EtherNet/IP 21 (38)
10 Network Specific — EtherNet/IP
10.1 Network Object (03h)
Attribute #1, Network
Type
The 30-series module is available in two network type versions, either with
“Beacon based DLR” (Highest performance) or with “Announce based DLR”
which both are Ethernet redundancy protocols. The 40-series is only available
with “Beacon based DLR”. The network type value differs between the versions.
Value Network Type Anybus CompactCom Product
0085h EtherNet/IP, No DLR 30-series 1-port
009Ch EtherNet/IP, Announce Based DLR 30-series 2-port
009Bh EtherNet/IP, Beacon Based DLR 30-series and 40-series
10.2 EtherNet/IP Host Object (F8h)
Attribute Default Anybus CompactCom
Product
Comment
#2, Device
Type
0000h 30-series, EtherNet/IP,
No DLR
If the attribute is implemented in the
host application, it overrides the de-
fault value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented,
the default value is used.
0000h 30-series, EtherNet/IP,
Announce Based DLR
002Bh 30-series, EtherNet/IP,
Beacon Based DLR
002Bh 40-series, EtherNet/IP,
Beacon Based DLR
#3, Product
Code
0063h 30-series, EtherNet/IP,
No DLR
If the attribute is implemented in the
host application, it overrides the de-
fault value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented,
the default value is used.
002Eh 30-series, EtherNet/IP,
Announce Based DLR
0036h 30-series, EtherNet/IP,
Beacon Based DLR
0037h 40-series, EtherNet/IP,
Beacon Based DLR
#6, Product
Name
Anybus-CC EtherNet/IP 30-series, EtherNet/IP,
No DLR
If the attribute is implemented in the
host application, it overrides the de-
fault value and there is no difference
between the 30-series and the 40-
series.
If the attribute is not implemented,
the default value is used.
CompactCom EtherNet/
IP(TM) 2P
30-series, EtherNet/IP,
Announce Based DLR
Anybus-CC EIP (2-Port)
BB DLR
30-series, EtherNet/IP,
Beacon Based DLR
Anybus CompactCom 40
EtherNet/IP(TM)
40-series, EtherNet/IP,
Beacon Based DLR
Attribute
#27, Produc-
ing Instance
Map
See comment Attribute removed in the 40-series
(only available in the 30-series Ether-
Net/IP Beacon Based DLR). The
CompactCom will never request this
attribute. Replaced by the functional-
ity in the Assembly Mapping Object
(EBh).
If this attribute is used, the Assembly
Mapping object must be implemented
instead.
Attribute
#28, Con-
suming In-
stance Map
See comment Attribute removed in the 40-series
(only available in the 30-series Ether-
Net/IP Beacon Based DLR). The
CompactCom will never request this
attribute. Replaced by the functional-
ity in the Assembly Mapping Object
(EBh).
If this attribute is used, the Assembly
Mapping object must be implemented
instead.
Migrating from Anybus
®
CompactCom
™
30 to Anybus
®
CompactCom
™
40 Design Guide SCM-1202-043 1.1
