Hardware Compatibility 10 (38)

4 Hardware Compatibility

Anybus CompactCom is available in three hardware formats; Module, Chip, and Brick.

4.1 Module

The modules in the 30-series and the 40-series share physical characteristics, like dimensions,

outline, connectors, LED indicators, mounting parts etc. They are also available as modules

without housing.

Fig. 1 Anybus CompactCom M30/M40

4.2 Chip

The chip (C30/C40) versions of the Anybus CompactCom differ completely when it comes to

physical dimensions.

There is no way to migrate a chip solution from the 30-series to the 40-series

without a major hardware update.

Migrating from Anybus

CompactCom

™

30 to Anybus

CompactCom

™

40 Design Guide SCM-1202-043 1.1
