HMS Anybus CompactCom 30 User Manual

Network Specific — Modbus-TCP 23 (38)
11 Network Specific — Modbus-TCP
11.1 Modbus Registers
Rearrangements have been made in the Modbus register map, because process data sizes
have been increased to 1536 bytes in each direction. An existing PLC configuration need to be
changed to use the new addresses. No difference on the application side.
Contents 30-series Modbus Address 40-series Modbus Address
Holding Registers (4x)
Read Process Data 0000h-00FFh 0000h-02FFh
Write Process Data 0100h-01FFh 0800h-0AFFh
Process Active Timeout 0203h 1003h
Enter/Exit Idle Mode 0204h 1004h
ADI Number 1 0210h-021Fh 1010h-101Fh
ADI Number 2 0220h-022Fh 1020h-102Fh
ADI Number 3839 FFF0h-FFFFh
Input Registers (3x)
Write Process Data 0000h-00FFh 0000h-02FFh
Diagnostic Event Count 0100h 0800h
Diagnostic Event #1 0101h 0801h
Diagnostic Event #2 0102h 0802h
Diagnostic Event #3 0103h 0803h
Diagnostic Event #4 0104h 0804h
Diagnostic Event #5 0105h 0805h
Diagnostic Event #6 0106h 0806h
Coils (0x)
Read Process Data 0000h-0FFFh 0000h-2FFFh
Discrete Inputs (1x)
Write Process Data 0000h-0FFFh 0000h-2FFFh
11.2 BOOL arrays
Process data mapped BOOL arrays are not compressed to bit-fields on the network in the 40-
series, but handled as a normal 8-bit datatype. To create bit-arrays in the 40-series, use the
new datatypes BITx instead.
Migrating from Anybus
®
CompactCom
™
30 to Anybus
®
CompactCom
™
40 Design Guide SCM-1202-043 1.1
