Network Specific — PROFINET 33 (38)

13.8.2 Module Status LED (LED2[A..B])

LED State 30-series 40-series Comments

Off Not Initialized Not Initialized No power or Module in SETUP or

NW_INIT state

Green Normal Operation Normal Operation Module has shifted from the NW_IN-

IT state

Green, 1 flash Diagnostic Event Diagnostic Event Diagnostic event(s) present

Green, cont. flash Identify

Flashing 1Hz continuously to identify

slave (DCP_Identify).

Red Exception error Exception error Module in state Exception

Fatal Event Fatal Event Major internal error (this indication is

combined with a red Network Status

LED)

Red, 1 flash Configuration error

Red, 2 flashes IP address error

Red, 3 flashes Station Name Error

Red, 4 flashes Internal error

Alternating Red/

Green

Firmware Update Do NOT power off the module. Turn-

ing the module off during this phase

could cause permanent damage.

13.9 SNMP MIB-II

sysContact, sysLocation and sysName are used to give the product identification in the end

installation.

In the 40-module these variables are only set from the network using SNMP protocol by the end

user.

Due to this, sysContact (PROFINET IO object (F6h), Attribute 22), sysLocation (Network Con-

figuration Object (04h), Attribute 17) and sysName (Network Configuration Object (04h), Attrib-

ute 15) are no longer used.

Nothing needs to be updated in your implementation but attribute values will no longer be used.

Migrating from Anybus

CompactCom

™

30 to Anybus

CompactCom

™

40 Design Guide SCM-1202-043 1.1
