7
6.0 USING THE MIXER.
6.1
OPERATING FOR THE FIRST TIME.
Check Lubrication before use.
This mixer is shipped with oil in the transmission. Check the oil level before starting the
mixer.
• Electrically isolate the mixer.
• Remove the top cover.
• Unscrew the dipstick using a 3/8” hexagon Allen key and check the oil level. The oil
level must be between the two grooves on the dipstick. Refer to figure 1 for the dip
stick position.
This food mixer is only for professional use by suitably trained
persons. Ensure operators have read and understood this manual
and have received adequate training. MOVING AGITATOR IN BOWL,
KEEP HANDS, CLOTHING AND UTENSILS OUT WHILE IN
OPERATION. DO NOT USE WITHOUT INTERLOCKED GUARD.
The Legacy mixer is equipped with Smart ™ Timer control and a power bowl lift. Other
operating parts (Fig.1, page 8) and their functions are described through out the
Operation section.
The Wire Cage guard must be in position or the mixer will not operate.
The bowl must stay in locked position on the Bowl Support or the mixer will not operate.
If the bowl support is not all the way up (mix position), the mixer will not operate unless
the START button is pressed and held.
If the bowl support is not in the mix position and the START button is pressed and held,
the mixer will operate only in Stir speed.
