Small roof light
Locking knob
1
Large roof light
Control pin
Small roof light
To open
• Thisroofbonnetcanbeopenedintheoppositedirectionto
trac.Pressthelockingknob
j
andusetheadjustingleverto
movetheroofbonnettothedesiredposition.
To close
• Guidetheadjustingleveralongtheguiderailandclosetheroof
bonnet.Thebonnetwilllockwhentheleverhooksintoplace
behindthelockingknob
j
.
Large roof light
Beforeopeningthelight,ensurethattheareaabovetheopening
ofthelightisfree.Thelightcanbeopenedtoanangleof60°.
To open
• Reachintotheopeningofthecrankbagandfoldthecrankto
theuserpositionbypullingitout.Turnthecrankclockwiseto
openthelighttothedesiredposition.Whenyouhavereached
themaximumopeningangleyouwillfeeltheresistance.
To close
• Turnthecrankcounter-clockwiseuntilthelightisclosedand
youfeeltheresistance.Thecontrolpin
j
isvisiblewhenthe
skylightisshut.Thenturnthecrankonlysofaruntilyoucan
folditintothecrankbag.Tobelockedsecurely,thecrankmust
befoldedintothecrankbag.
Themaximumspeedis130km/h,becausenoisemay
be generated or damage caused, depending on the
superstructureorplaceofinstallation.
Insect screens and shades (plissés)
Bothplissésarefullyadjustablebyslidingthemhorizontallyfrom
sidetoside.
