6. Interior structure
62
Open shade/insect screen
5
3
4
Roof fan (washroom)
Roof fan (washroom)
Roof fan lock
1
2
1
Roof fan (washroom)
Therooffancanbesetupeitherononeorbothsides.
To open
• Pressthespringlock
j
diagonallyupwardstowardstheinside
oftherooffanuntilitunhooksfromitslockingmechanism.At
thesametime,usingthehandle
k
topresstherooffanup-
wards.
To close
• Usebothhandles
k
topulltherooffanrmlydownwardsuntil
bothspringlocks
j
havelatchedintoplace.
Shade/insect screen
To close
• Pulltheguiderail
l
ofthescreentotheoppositesideand
hookthelock
m
intothecounterpart
n
.
To open
• Pressthelockandtiltitslightlytoenableittounhookfromthe
counterpart.
• Slowlyguidethescreenbackalongtheguiderail.
