Holzmann BS 115 - Operation; Adjustment before Initial Startup; Check the Screws; Select the Saw Blade Speed

OPERATION
HOLZMANN Maschinen GmbH www.holzmann-maschinen.at Seite 35
BS 115
14 OPERATION
4.1 Adjustment before initial startup
14.1.1 Check the screws
Check before commissioning all screw connections and pull it if necessary.
WA R N IN G
Perform all the conversion work in isolation from the mains!
14.1.2 Select the saw blade speed
The saw blade is driven via a belt drive. Adjust the saw blade speed at the material to be cut.
Select the feed according to the following table.
Material
speed
(m/min)
Belt position
Motor pulley
Drive pulley
Saw band
Stainless Steel
Stainless Steel ®
Tool steel
Alloy steel
Bearing bronze
20
A
D
Bi-Metal
Structural steel
iron
mild steel
Thomas steel
29
B
E
Bi-Metal
Brass
Aluminium
Similar materials
50
C
F
HSS
Motor pulley Drive pulley
