Raise the arm band saw in the 90 ° position and clamp
it on the base console with the fixing bracket.
The work talbe with the two screws attach on the
bandsaw blade guide.
Loosen the fixing screw at the bandsaw blade guide.
Insert the support bracket by the fixing screw
Screw on the table top with the countersunk screw up
and the washer and nut below.
The top bandsaw blade guide by unscrewing the fixing
nut (12) and screw into the threaded hole 2. be
pushed deeper.
As a result, the bandsaw blade is made even better.
