Holzmann BS 115 - Ersatzteil-Liste; Spare Part List

ERSATZTEILE / SPARE PARTS
HOLZMANN Maschinen GmbH www.holzmann-maschinen.at Seite 48
BS 115
18.3 Ersatzteil-Liste / spare part list
No.
Part Name
Qty
No.
Part Name
Qty
1
Rubber pad
2
40
Rubber sleeve
1
2
Steel Bracket
4
41
Magnetic switch
1
3
Flat washer
18
42
Screw
2
4
Elastic washer
15
43
Adjusting bar
1
5
Nut
16
44
Fixing plate (A)
1
6
Nut
10
45
Rear clamping plate
1
7
Elastic washer
15
46
Big flat washer
3
8
Flat washer
16
47
Bolt
2
9
Bolt
9
48
Front clamping plate
1
10
Support leg
2
49
Bolt
1
11
Ear ring
2
50
Bolt
1
12
Carrying handle
1
51
Bolt
1
13
Bolt
7
52
Bolt
1
14
Screw
2
53
Turning shaft
1
15
Position block
1
54
Connecting block
1
16
Sliding bar
1
55
Big flat washer
2
17
Flat washer
9
56
Screw
2
18
Locking nut
2
57
Screw
2
19
Bolt
2
58
Screw
1
20
Cable and plug
1
59
Switch pressing bracket
1
21
Strain relief
2
60
Flat pin
1
22
Switch box support bracket
1
61
Screw
1
23
Teeth washer
2
62
Gear wheel
1
24
Elastic washer
7
63
Ball bearing
4
25
Screw
2
64
Oil seal
3
26
Elastic washer
4
65
Gear wheel tube
1
27
Screw
2
66
Retaining ring
1
28
Bolt
2
67
Cover plate
1
29
Switch box
1
68
Screw
6
30
Flat washer
9
69
Bolt
1
31
Screw
4
70
Wheel shaft
1
32
Switch box cover
1
71
Position tube
1
33
Screw
4
72
Flat pin
1
34
Screw
1
73
Drive wheel
1
35
Wheel bar
1
74
Retaining ring
2
36
Turning wheel
1
75
Bolt
1
37
Thread bar
1
76
Blade
1
38
Thread bar nut
1
77
Upper blade guide
1
39
Position holder
1
78
Locking knob
1
