Homematic IP HmIP-FALMOT-C12 User Manual

47
General system information
Cable bushings (see figure 2):
(K) Cable bushing for DC-IN
(L) Cable bushing for DC-IN
(M) Cable routing for motorised drives
(N) Cable routing for extension box
Unlike conventional thermal actuators, the mo-
torised actuator can move to any valve position
calculated by the floor heating actuator in order
to reach the desired room temperature. This re-
sults in an even heat flow and continuous heat
dissipation. When switching from conventional to
motorised actuators, flow noises may occur in
rare cases at the heating circuit distributor if the
pump pressure setting is high and the valve ope-
nings are small. You can correct this by changing
the pump settings or by adjusting the parameters
of the floor heating actuator.
4 General system information
This device is part of the Homematic IP smart home sys-
tem and works with the Homematic IP radio protocol. All
devices of the system can be configured comfortably and
individually with the Homematic IP smartphone app. Al-
ternatively, you can operate the Homematic IP devices
via the Central Control Unit CCU2/CCU3 or in connec-
tion with various partner solutions. The available func-

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
