Homematic IP HmIP-FALMOT-C12 User Manual

54
Start-up
figure 7).
• Press and hold down the system button (A) for 4
seconds until the LED (A) quickly starts flashing
orange (see figure 6). Pairing mode remains acti-
vated for 3 minutes.
• Press and hold down the system button of the
Multi IO Box for at least 4 seconds to activate the
pairing mode. The device LED flashes orange.
The device LED (A) lights up green to indicate that pairing
has been successful. If pairing failed, the device LED (A)
lights up red. Please try again.
6.4.3 Adding a new floor heating actuator
To add a new floor heating actuator to the system or to
the existing devices, please proceed as follows:
• First pair the new floor heating actuator with an
existing one. Activate the pairing mode of the ex-
isting floor heating actuator. Therefore, press and
hold down the system button (A) for at least 4
seconds (see figure 6).
• Activate the pairing mode of the new floor heating
actuator. Press and hold down the system button
(A) for at least 4 seconds.
The device LED (A) lights up green to indicate that
pairing has been successful. If pairing failed, the
device LED (A) lights up red. Please try again.

Homematic IP HmIP-FALMOT-C12 Specifications

General

Input voltage	24/230 V
Input frequency	50 Hz
Power source type	AC, DC
Maximum switching capacity	0.2 W
Frequency	869.65 MHz
Cable length	1.5 m
Display type	LCD
Product type	Heating actuator
Product color	White
Built-in display	Yes
Channels quantity	12 channels
Maximum outdoor range	320 m
International Protection (IP) code	IP20
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	52 mm
Width	242 mm
Height	85 mm
Weight	440 g
Package depth	281 mm
Package width	184 mm
Package height	97 mm
Package weight	917 g
